Forged Steel Rolls for 19-roller plate pipe bar straightening machine

The pipe and bar straightening machine is staggeredly arranged by using up and down tilting straightening rollers, so that the bars are rotated and advanced under the friction force of the straightening roller to generate plastic bending deformation to achieve straightening.

It is possible to straighten pipes and rods of Φ6-Φ50mm, and use different types of straighteners for different specifications.

19-roller plate straightening machine

Specifications:

Thickness of sheet plate:0.3-3 mm
Width of coiled plate:500-1600mm
Precision of leveling:0.2mm/2000mm
Weight of machine :around 8 MT

1. Application : carbon steel plate, galvanized sheet, color plate, stainless steel,

Hot rolled ,cold rolled etc. b≤450Mpa;S ≤260Mpa,

2. Thickness of sheet plate: 0.3-3 mm;

3. Width of coiled plate: 900-1600 mm;

4. Precision of leveling: length tolerance: ±0.2mm/2000mm;

diagonal tolerance: ±0.2mm/2000mm;

unevenness is according to GB stipulations

5. Levelling speed: 0-20m/min ;

6. The roller diameter: 65 mm ; 17+2 pcs.

7. The roller form :60mm

8. Hardness of blade: HRC58°—60°;

9. Motor power: 30 Kw

Beijing Sino Steel Engineering & Equipment Co., Ltd. is concentrating on developing of ferrous & non-ferrous making and Rolling technology, mainly.

As one of the most experienced Chinese suppliers of complete line and components for steel and non-ferrous industries, Beijing Sino Steel Engineering & Equipment Co., Ltd. is engaged in design, manufacturing, engineering and service activities on word-wide basis.

Overseas Partners (Office):

India, Indonesia, Malaysia, Thailand, Korea, Turkey, UAE, Qatar, Iran, Saudi Arabia, Kuwait, Germany, France, Canada, USA, Brazil, Etc.

MAIN SCOPE SUPPLY:

EPS Project Line:

EAF, LF, Continuous Casting Machine, Preheating Furnace, Hot Rolling Mill Line, Cold Rolling Line, Centrifugal Casting Line, Slitting Line,Cut-to-length Line, Cleaning Line, Pickling Line, Coating line, Levelling line, Billet grinding line ETC.

Components & Parts:

Mill stand, Coiler, Uncoiler, Gearbox, Leveller, Copper Mould Tube, Copper Mould Plate, Water Jacket, Water Cooled Cable, Forged Rolls, Casting Rolls, Roll Shell, Roll Core,Bearing, Universal Shaft, Lathe, ETC.

​
