Rolling Mill Stand slab mill rebar mill wire rod mill plate mill

1. Medium plate hot rolling line

Steel grade: Carbon steel, Alloy steel

Thickness: 6-45mm

Width : 1200~2600mm

Length: Max 18000mm

Unit plate: 4.6 ton Max.

Screw-down has the electrical APC；

The precision of the rolling control depend on hydraulic AGC；

The mill has the section cooling of the roll, high pressure water descaling and the dust cleaning.

It has the roll gap meter and rolling pressure meter. These signal can be used as the feedback of the pressure and position.

The work roll bearing was four row tapered roller bearing. The backup roll bearing was dynamic pressure oil film bearing.

The material of the work roll was indefinite chill cast iron. The material of the backuproll was special alloyed forged steel.

The bottom of the mill has the device of ladder cushion. The height of the lower roller can be adjust automaticly.

The final mill has the function of working roll bending.

It reserved the Vertical Edger after the roughing mill stand. This vertical Edger has the AWC system. It can control the width of the plate. It also can control the shape of the head and tail of the plate. The yield rate can be improved accordingly.

The work roll assemble and the backup roll assemble can be changed quickly. The working roll and the backup roll can be send to the roll grinding shop directly and be regrinded and assembled there.

Rebar Hot rolling mill

Materials Specifications

Continuous casting square billet size is 150mm x 150mm; the length of the continuous casting billets inside the furnace need to be controlled around 6000 ~ 12000mm. Optimizing and length requirements are based on product specifications, with a predetermined length of the continuous casting billets putting into the furnace.

Common Product and Standard

Beijing Sino Steel Engineering & Equipment Co., Ltd. is concentrating on developing of ferrous & non-ferrous making and Rolling technology, mainly.

As one of the most experienced Chinese suppliers of complete line and components for steel and non-ferrous industries, Beijing Sino Steel Engineering & Equipment Co., Ltd. is engaged in design, manufacturing, engineering and service activities on word-wide basis.

Overseas Partners (Office):

India, Indonesia, Malaysia, Thailand, Korea, Turkey, UAE, Qatar, Iran, Saudi Arabia, Kuwait, Germany, France, Canada, USA, Brazil, Etc.

MAIN SCOPE SUPPLY:

EPS Project Line:

EAF, LF, Continuous Casting Machine, Preheating Furnace, Hot Rolling Mill Line, Cold Rolling Line, Centrifugal Casting Line, Slitting Line,Cut-to-length Line, Cleaning Line, Pickling Line, Coating line, Levelling line, Billet grinding line ETC.

Components & Parts:

Mill stand, Coiler, Uncoiler, Gearbox, Leveller, Copper Mould Tube, Copper Mould Plate, Water Jacket, Water Cooled Cable, Forged Rolls, Casting Rolls, Roll Shell, Roll Core,Bearing, Universal Shaft, Lathe, ETC.

​
