    Narrow Side Copper Plated Aluminum Sheet Flat Optional Size Electical Conductivity

    Ask Lasest Price
    Brand Name : SEEC
    Model Number : CCM
    Certification : ISO
    Delivery Time : 2-3months
    • Product Details
    • Company Profile

    Narrow Side Copper Plated Aluminum Sheet Flat Optional Size Electical Conductivity

    Copper mould plate Narrow plate working life 25000~30000 tons each coating


    • Our specialized know-how, quality control and service enable us to satisfy the market’s changing requirements. Concentrating on adaptability to the improvement of continuous casting technology with continuously ongoing research and development word, BEIJING SINO STEEL is providing optimal solutions to your moulds.

    • Reference Working Life

    • Stainless steel

    Less than 2000 mm X180mm (billet dimension):25000~30000 tons/each coating

    More than 2000 MM X180MM (billet dimension):80000~120000tons/each coating


    • Carbon steel

    Less than 2000 mm X180mm (billet dimension):30000~40000 tons/each coating

    More than 2000 MM X180MM (billet dimension):100000~150000tons/each coating


    Note: It can be remilled and recoated for 3~5 times.


    China Market Share: 20~30%


    1. Material
    MaterialChemical CompositionMechanical PropertiesElectric Conductivity (%IACS)

    Cu

    (%)

    Others

    (%)

    Tensile Strength σ b (N/mm2)Yield Strength σ 0.2 (N/mm2)

    Elongation

    δ

    (%)

    Hardness (HB)
    E-Cu>99.9020040404598
    SF-Cu>99.85P0.015-0.040240-310190-25025-1080-9585

    CuAg>99.50Ag0.08-0.12240-310200-22516-10110-12595
    Cu-Cr-Zr>98.0

    Cr0.3-1.2

    Zr0.08-0.3

    375-445280-35520-13115-13080

    MaterialCuAg, Cu-Cr-Zr
    DesignH-beam
    Rectangular
    Size

    H-beam: 700-1016x280-1000 (LxW)

    Wall thickness:35-310mm


    Rectangular:Max 5000mm×3800mm (L x W)

    Wall thickness:30-75mm

    CoatingCoating material: Cr, Ni-Co or Ni-Fe

    1. Product Scope:

    MaterialCuAg, Cu-Cr-Zr
    DesignH-beam
    Rectangular
    Size

    H-beam: 700-1016x280-1000 (LxW)

    Wall thickness:35-310mm


    Rectangular:Max 5000mm×3800mm (L x W)

    Wall thickness:30-75mm

    CoatingCoating material: Cr, Ni-Co or Ni-Fe

    Material Details:


    ltemTempUnitMaterial
    CuDHPCuAg0.1CuCrZr
     Chemical Composition

    Cu 99.85

    P0.015-0.040

    Cu 99.50

    Ag0.08-0.12

    Cu 98

    Cr 0.30-1.20

    Zr 0.08-0.30

     Physical properties
    Electical conductivity20%IACS859580
    Thermal conductivity20W/(m.K)340375330
    Coefficient of thermal expansion20-30010^-6/K17.117.117.2
    Recrystallisation temperature345360690
    Modulus of elasticity2010^3MPa120123126
    Melting point108310831078
    Specific gravityg/cm38.98.98.9
     Mechanical properties
    Ultimate tensile strength20Mpa240-310240-310375-445
    Ultimate tensile strength100Mpa190-270230-270365-425
    Ultimate tensile strength200Mpa140-190205-240365-410
    Ultimate tensile strength300Mpa175-210335-375
    Ultimate tensile strength400Mpa145-160315-350
    0.2Yield point strength(Rp0.2)20Mpa190-250200-225280-355
    0.2Yield point strength(Rp0.2)100Mpa185-260195-240270-345
    0.2Yield point strength(Rp0.2)200Mpa180-225260-330
    0.2Yield point strength(Rp0.2)300Mpa165-215250-320
    0.2Yield point strength(Rp0.2)400Mpa130-145240-290
    Elongation(A5)20%25-1016-1020-13
    Hardness20HB80-95110-125115-130
    Note: TP2(GB/T5231-2001)Equivalent SF-Cu/DHP-Cu(DIN1787)
    TAg0.1(CuAg0.1)(GB/T5231-2001) Equivalent DPS-Cu(DIN1787)
